Aluminium Led Chanel Profile Lighting Strips Extruded Decorative Wall Mount Corner
Application
Outstanding Anodized Aluminium profiles for LED strip lighting for kitchen, floor, under cupboard, plint, drywall and tile application.It gives modern, elegant and diffuse light to the direction you need. In addition these profiles extend the led life life time by functioning as heatsink.
Feature
When designing LED strip lights, it is important to create a professional and finished look. Unhoused lighting solutions just don’t look good when exposed, especially if the location of the install is where it can be easily seen. Another advantage is that these aluminum industry solutions can help to prevent moisture from getting into the LED strip lighting. While not 100 percent waterproof, there are some additional things that can be done to make it waterproof, if that is what is required. The extruded aluminum provides a base that can be further customized to meet the demands of the project to provide the desired results.
Use
Extrusions can be fixed in place using countersink screws, straight into the extrusion. Alternatively, you can purchase fixing brackets if you prefer. These can be attached in place, and once they are in position, your extrusion can be clipped onto them.
- Ensure the channel is cut to the length you require and screw the mounting bracketsinto the surface of choice at 1m intervals.
- Peel the adhesive backing off the run of LED tape and stick the length of the tapeinto the channel.
- Clip the diffuser onto the channel.
- Insert the end clips onto each end of the profile, ensuring the 2 core cable is threadthrough the hole in one of the end caps. This cable will attach to the driver or powersource.
- Press the profile firmly into the mounting brackets so they click into place.
Specification
| Products Name | Aluminum LED Profile |
| Model | RC003 |
| Material | 6063-T5 Aluminum Alloy + PC |
| PC cover material | Clear,semi-clear,opal matte |
| Accessories | End caps + Mounting brackets |
| Available lengths | 2m or custom |
| IP rate | IP rate |
| LED | SMD2835/5730/5050/3528/3014/2216/COB for options |
